Product description
Size: 55 "and other size: - 82，108 inches
LCD panel
55 inch (16:9)
Color color 16.7 million true color
More than 1000 degrees to: 1
Bright degree 700 CD/m 2
Visual Angle level: 178 ° vertical: 178 °
Response time 3 millisecond
Points distinguishing rate 1920 x 1080
Screen life > 60000 hours
1080 p full hd LCD advertisement machine adopts the latest generation full hd multimedia decoding scheme. The scheme integration design, not only screen drive and advertising machine multimedia decoding high integration, to reduce a signal attenuation, improve the quality and degree, and convenient installation and maintenance after use. The scheme advertising machine is mainly adaptor TFT LCD PANLE, using high performance MST6M48 main chip, the chip containing 3 d COMB FILTER and 3 d DEINTERLACE, better demodulation out all kinds of input signal. Contains powerful audio/video processing function, and can output high quality pictures and sound quality. 2 road USB 2.0, support pictures broadcast, music play and video broadcasting, support 1080 p within the input (including 480 p, 720 p, 1080 p), support WUXGA (widescreen super extended image display) (1920 x0180 @ 60 hz) high-definition input signal and output effect and provide better by ways of high-definition video, and at the same time, has strong audio power amplifier, can provide 2 x6w output power, energy saving and low energy consumption, standby power consumption less than 1 w. The main performance parameters: support format
Video format MPG \ MPG - 1 \ MPG - 2 \ MPG - 4 \ AVI \ MP \ TS \ DIV \ TRP \ MKV \ WMV \ RM/RMVB
Picture format JPG \ BMP
Audio formats MP3, WMA
Video decoding support
The maximum resolution 1920 * 1080/1920 * 1200
Maximum color depth 24 bit
Maximum frame speed 30 FRM/s
Maximum code flow USB 2.0 device: 30 MB/s
Audio decoding support
Sampling rate and kHz \ 44.1 kHz, 48 kHz \ 96 kHz
Bit rate and KBPS to 384 KBPS
Other parameters
Power DC12V / 300 ma
Power ﹤ 3 w
Frequency response ± 3 db (20 hz - 20 KHZ
Crosstalk 75 db
Audio output 47 k Europe impedance
Video output CVBS 75 Europe impedance
USB transmission rate USB 2.0 Max 480 MB
Product function: support cross screen/vertical screen play
Boot automatic cycle play
Support breakpoint memory play function
Support video advertising spot function
Support function of time switch machine
Support large BMP GuaJiao icon display function (similar to the TV station mark play function)
Support long flowing water subtitles display function (rolling subtitles shown)
Supporting documents directly on the phone copy and delete functions
Support USB file updating function
Automatically generate play log record function (easy to advertisers inquires the play record) without any manual operation
Support the full screen/split screen play function (split screen display need to customize split screen module can realize, for optional function)
Time-sharing volume, different time, can set different play volume
The highest support 1080 p (resolution for 1920 * 1080) non-interlaced hd scanning display and interlaced hd scanning display (namely 1080 I, resolution 1920 * 1080)
Support USB play, support hot plug, content updates convenient and quick
Support for audio and video formats: MPG \ MPG - 1 \ MPG - 2 \ MPG - 4 \ AVI \ MP4 \ DIV \ TS \ TRP \ MKV \ WMV \ RM/RMVB, JPG, BMP, reading and other mainstream play format
Playback modes: single cycle broadcast, folder circulation broadcast, full circulation broadcast
Pictures play: rotation, scaling, translation, slide broadcast, by synching up background music playing
Audio mode: left channel, right sound channel, stereo sound track
OSD menu multinational language: support Chinese, English, and other national language (in Sino-British is given priority to, other need to modify the software language pack)
Support Chinese, English water rolling subtitles, xtras subtitles
Support time perpetual calendar function
Support access function panel key function (special function optional)
High brightness, the resolution is good quality (support brightness, contrast, color temperature parameters such as manual regulation)
Support USB directly software program update and upgrade
Network scheme (optional)
Touch program (optional)
